M1 is an Official Car Builder to the Trans Am Series

M1 is an ‘Official Car Builder’ to the Trans Am Series presented by Pirelli

We utilize our race-winning technology to produce the most stable and predictable racecar on the track today. Just ask any driver or team who has experienced the "M1 Difference."

The proprietary chassis design by M1 has been CAD-perfected by our engineering staff to ensure that each completed chassis is identical and performs as expected. Our chassis materials are CNC mandrel bent and cut to our exacting standards, which results in the most precise and cost effective build.

TeamSLR is the exclusive distributor for M1 Racecars worldwide. TeamSLR also provides M1 with vital technical assistance and on-track feedback to support our performance development efforts.

This combination has been a powerful asset to M1 and to every M1 customer, which has included the championship-winning Peterson Racing organization, Guthrie’s Garage, Troy Benner Autosport, Carroll Racing Enterprises, Brown Brothers Racing, and Big Machine Racing.

TeamSLR M1 Racecars TA2 Specifications

Chassis & Body:

Chassis: M1 Racecars tubular space-frame chassis, with CNC cut, bend and notch for precision build.
Body: The race team utilizes Generation Six Chevrolet Camaro by Five Star RaceCar Bodies, made with advanced lightweight composite and ultraglass. All chassis and body brands are available to M1 Racecars customers.
Minimum Dimensions: Length 189.5 inches; Width 72-3/4 to 79 inches; Height 48-1/2 inches.
Minimum Weight: 2,830 lbs. (including driver)

Engine & Performance:

Engine: 515 horsepower with 6,800 rpm limiter, by PME Engines
Engine Type: Trans Am spec modified GM LS3 all-aluminum engine with external, three-stage dry sump oiling system
Fuel: Sunoco Race Fuels, 98 octane
Top speed: 165+ mph (varies by track layout)

Drivetrain:

Transmission: Andrews 4 speed H-Pattern
Rear End: Tiger quick-change rear end

Brakes & Suspension:

Brakes: Pro Systems six-piston caliper front brakes (12.19 rotor), Pro Systems four-piston caliper rear brakes (11.75 rotor)
Suspension: Double wishbone front suspension and three-link rear suspension
Shocks: JRI, Penske, Ohlins
Brake Calipers: Pro Systems
Brake Rotors: Pro Systems

Wheels & Tires:

Wheels: 15-inch diameter x 10-inch wide, 5x5 painted steel Basset racing wheels
Tires: Pirelli P Zero racing slicks, 275/695-15

Other Notable Features:

Fuel Capacity: 26-gallon fuel cell
Electrical: AIM, Motec Dash
Rear Wing: Single-plane rear wing
No driver aids: i.e. traction control, ABS
Windows: Polycarbonate windows with a tear-off film
Cost-Controlled Components: Many components are controlled and must be purchased from the vehicle’s distributor
